Step 11
Screw temperature gauge fully into lid.
Slightly unscrew temperature gauge until
gauge is in an upright position. Use pre-
attached nut to lock into place. Repeat for
other temperature gauge.
Step 12
Attach grill handles using eight
M4 X 10 mm bolts and M4 nuts.
Step 13
Attach lid stopper to each lid using one
M4 X 10 mm bolt for each lid stopper.
Step 14
Attach the air vent using six M6 X 10 mm
bolts as illustrated.
29
