Step 15
Attach the grill side handle to the charcoal
body using four M6 X 10 mm bolts.
Step 16
Attach main control panel assembly to gas
grill using four M6 X 10 mm bolts from
inside gas grill body.
Step 17
Insert electrode wire and burner openings
through burner holes in gas grill bottom.
Orient burners CORRECTLY by aligning
screw holes in burner to left as shown.
Secure burner tubes using three
M6 X 10 mm bolts.
Note: Make sure burner opening slides
over valve nozzle.
30
