Inspect contents of the box to ensure all parts are included and undamaged.
TRAILMASTER 30"
3
We recommend two people work together
when assembling this unit.
The following tools are required to assemble
this Trailmaster:
• Hammer
•
9
⁄
16
" Wrench or Adjustable Wrench
PARTS LIST:
1 Cooking chamber
1 Air vent butterfly damper
1 Half air exhaust damper
2 Cooking grills (14"x 154")
2 Charcoal grates (9" x 14")
1 Front shelf
2 Legs with endcaps
2 Legs with axle receivers
252" wagon wheels
1 Firebox door latch
1 Firebox rake
1 End handle
1 Axle rod
Parts Bag Contains:
4 w" Washers
2 d" Axle caps
1
2
3
4
5
6
7
8
9
10
12
13
11
1
3
7
8
13
11
12
9
4
2
5
6
10
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR SMOKER.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
(PROOF OF PURCHASE WILL BE REQUIRED.)
