BRIO TROE600PRISM - Install Faucet

10
4. Install the Faucet
A. Ensure that you have a mounting hole in your sink or countertop for this faucet. If you do not, create a
mounting hole no less than 1.0–1.2 in. (2.54–3.0 cm).
B. Remove the washer (13) and lock nut (14) from the faucet (B). Ensure that you leave the O-ring (8) on the faucet.
C. Attach the 1/4 in. quick connector (L) to the stem outlet.
B
8
13
14
L
D. Insert the faucet into the mounting hole and secure in place underneath the sink with washer (13) and locknut
(14).
E. From underneath the sink, attach the faucet tube (K) to the 1/4 in. quick connector (L).
13
14
L
K
