Brivis ICE DO-SC22Z9 - Outdoor Unit

Specifications subject to change without notice. © 2013 Brivis Climate Systems Pty Ltd
7
2.4 Outdoor Unit
Fig. 5 - Outdoor Unit Major Components
Scroll
Compressor
Suction
Accumulator
Suction Line
Service
Ball valve
Liquid Line
Service
Ball valve
LP Switch
HP Switch
Electric Panel
Liquid filter Drier
Fan Run Capacitors
3 phase power
Supply connection
3 Phase Contactor
