Table 7: System Power LED Patterns during Normal Operation
LED Color Status of Hardware Recommended Action
No light System is off or there is an internal power
supply failure.
Verify that system is powered on, the power
cables attached, and your power source is
live.
If the system power LED is not green, the
unit may be faulty.
Contact your solution provider.
Steady green System is on and power supplies are
functioning properly.
No action required.
System Status LED
See the following table to interpret the system status LED.
Table 8: System Status LED Patterns during Normal Operation
LED Color Status of Hardware Recommended Action
No light System is off or there is no power. Verify that system is on and has completed
booting.
Steady green POST and initialization is completed.
System is on and functioning properly.
No action required.
Steady amber (for more than five seconds
—can take over a minute to complete
POST)
System is going through the power-up
process.
No action required.
Steady amber (for more than a few
minutes)
Unknown state, boot failed, or the system is
faulty.
When POST completes and the switch has
failed, steady amber may result.
Perform the following steps:
1. Connect a serial cable to the system.
2. Reboot the system.
3. Check the failure indicated on the
system console
4. Contact your solution provider.
Flashing amber/green Attention is required. A number of variables
can cause this status, including power
supply failure, a fan failure, or one or
more environmental ranges have been
exceeded.
Check the management interface and the
error log for details on the cause of the
status.
Contact your solution provider.
Management Port LEDs
See the following table to interpret the management port LEDs.
Table 9: Management Port LED Patterns during Normal Operation
LED Function/State Status of the Hardware
Link/SpeedGreen LED; ON 1000Mb/s Link
Link/Speed Amber LED; ON 10/100Mb/s Link
ActivityGreen LED: BLINK Presence of activity
53-1004408-11
54
Broadcom
