The vrid num option species the virtual router ID. Enter a value from 1 through 255.
Displaying summary information
To display summary information for a Layer 3 switch for VRRP, enter the show ip vrrp brief command at any level of the CLI.
device# show ip vrrp brief
Total number of VRRP routers defined: 1
Interface VRID CurPri P State Master addr Backup addr VIP
1/1/6 1 255 P Init 192.53.5.1 192.53.5.3 192.53.5.1
To display summary information for IPv6 VRRP, enter the show ipv6 vrrp brief command at any level of the CLI.
device# show ipv6 vrrp brief
Total number of VRRP routers defined: 1
Interface VRID CurPri P State
1/1/5 1 255 P Master
Master addr: Local
Backup addr: 2001:DB8::212:f2ff:fea8:3900
VIP : 2001:DB8::1
To display summary information for IPv6 VRRP-E v3 , enter the show ipv6 vrrp-extended brief command at any level of the CLI.
device# show ipv6 vrrp-extended brief
Total number of VRRP-Extended routers defined: 3
Interface VRID CurPri P State Master addr
1/1/1 1 100 P Master Master addr: Local
Backup addr: 2001:DB8::212:f2ff:fea8:5b00
VIP : 2001:DB8::100
1/1/2 2 150 P Master Master addr: Local
Backup addr: 2001:DB8::212:f2ff:fea8:5b00
VIP : 2001:DB8::100
v51 100 100 P Master Master addr: Local
Backup addr: 2001:DB8::212:f2ff:fea8:5b00
VIP : 2001:DB8::100
The table shows a description of the output for the show ip vrrp brief and show ip vrrp-extended brief commands.
TABLE 105 Output description for VRRP or VRRP-E summary information
Field Description
Total number of VRRP (or VRRP-Extended) routers dened The total number of VRIDs congured on this Layer 3 switch.
NOTE
The total applies only to the protocol the Layer 3 switch is
running. For example, if the Layer 3 switch is running VRRP-E,
the total applies only to VRRP-E routers.
Interface The interface on which VRRP or VRRP-E is congured. If VRRP or
VRRP-E is congured on multiple interfaces, information for each
interface is listed separately.
VRID The VRID congured on this interface. If multiple VRIDs are congured on
the interface, information for each VRID is listed in a separate row.
CurPri The current VRRP or VRRP-E priority of this Layer 3 switch for the VRID.
P Whether the backup preempt mode is enabled. If the backup preempt
mode is enabled, this eld contains a "P". If the mode is disabled, this eld
is blank.
State This Layer 3 switch VRRP or VRRP-E state for the VRID. The state can be
one of the following:
• Init - The VRID is not enabled (activated). If the state remains Init
after you activate the VRID, make sure that the VRID is also
Displaying VRRP and VRRP-E information
FastIron Ethernet Switch Layer 3 Routing
53-1003627-04 543
