1-5
General
: (continued)
Extension: W/O Boom Extension
With Boom Extension
Sheave Height (Nominal): 60.7 feet (18.47m) 79.5 feet (24.23m)
Horizontal Reach: 50.1 feet (15.27m) 70.1 feet (21.36m)
Weight:
Total 37,700 pounds (17100kg)
Front Axle 17,100 pounds (7800kg)
Rear Axle 20,600 pounds (9300kg)
Turning Radius: (4-Wheel Steering) 14.3 feet (4.37m)
Aisle Width for 90° Turn 11.9 feet (3.63m)
Steering Modes Rear Steer, Round Steer, Crab Steer
Road Speed 19 MPH (30.6km/h)
Cummins 3.3L GM5.7L
Drawbar Pull 17,700 pounds* (8000kg) 21,400 pounds* (9700kg)
Gradeability 64 percent* (33 degrees)
*Calculated, Wheels spin below these values in 2-wheel drive.
Grade Limit 15 percent (9 degrees)
Engine:
Standard:
Cummins QSB3.3L Turbo, EPA Tier 3:
Cummins Model QSB3.3 turbocharged diesel engine. Water cooled, 4-
cylinder, 199 CID, 3.74-inch bore, 4.53-inch stroke, 99 HP at governed
speed of 2500 RPM. Maximum torque is 304 ft-lbs at 1400 RPM. 120-amp
alternator included. 30-gallon fuel tank capacity. High temperature and low
oil pressure shutdown included in engine management system. Throttle
control switch for setting engine speed at 1200 or 1800 RPM. Charge air
cooler and grid heater included. (Net Weight: 200 pounds)
Spark Arrester Muffler:
Spark arrester muffler used in addition to standard muffler. (Net Weight:
10 pounds)
Catalytic Converter:
Catalytic converter for diesel engines. Reduces engine emissions. (Net
Weight: 10 pounds)
Engine Heater:
Heater for engine. Engine coolant heater installed with hoses in coolant
system to circulate warm water through engine. Plugs into 120V AC
extension cord. 1500 watts.
Cummins QSF3.8L Turbo, EPA Tier 4F:
Cummins QSF3.8 Tier 4 Final turbocharged diesel engine. Water cooled,
4-cylinder, 229 CID (3.8L), 4.02-inch (102 mm) bore, 4.53-inch (115 mm)
stroke, 130 HP (89 kW) at governed speed of 2500 RPM. Maximum torque
is 360 ft-lbs (488 Nm) at 1600 RPM. 135-amp alternator included. 30-
gallon (114 L) fuel tank capacity. High temperature and low oil pressure
