Page 54/58IOM BiRotor Plus R27
13.6 - BiRotor Plus Illustrated Parts List E2 Series [B35X and B36X]
Item Description Part Number Qty
Measuring Unit Assembly 110200-000
1 Measuring Unit Body 110211-100 1
2 Rotor Set R W110286 1
3 Rotor Set L W110286 1
4 End Plate (Inlet) 110285 1
5 End Plate (Outlet) 110824 1
6 Pulse Wheel 110083 1
7 Timing Gear Set R W110296 1
8 Timing Gear Set L W110296 1
9 Bearing (Inlet) 1501188 2
10 Bearing (Outlet) 1501189 2
11 Nut 110821 4
12 Set Screw 150982 8
13 Screw 15001296 12
14 Dowel Pin 1501106 4
15 Dowel Pin 1501193 1
16 Screw 1501294 1
17 Washer 1501295 1
18 Gear Lockwasher 112293 2
19 Gear Locknut 112292 2
20 Bearing Spring 1501196 4
Bearing Kit WB36C-BK-001 1
