IOM BiRotor Plus R27Page 55/58
Item Description Part Number Qty
Measuring Unit Assembly 116200-000
1 Measuring Unit Body 116211-100 1
2 Rotor Set R W116286 1
3 Rotor Set L W116286 1
4 End Plate (Inlet) 116825 1
5 End Plate (Outlet) 116826 1
6 Pulse Wheel 116083 1
7 Timing Gear Set R W116296 1
8 Timing Gear Set L W116296 1
9 Bearing (Inlet) 1501184 2
10 Bearing (Outlet) 1501185 2
11 Nut 116821 4
12 Set Screw 150982 8
13 Screw 1501187-019 12
14 Dowel Pin 1501188 4
15 Dowel Pin 1501189 1
16 Screw 1501190-019 1
17 Washer 1501191 1
18 Lock Washer 1501192 1
19 Gear Lockwasher 112293 2
20 Gear Locknut 112292 2
21 Bearing Spring 1501196 4
Compelte Repair Kit WB38C-BK-001 1
13.7 - BiRotor Plus Illustrated Parts List F Series [B38X]
