APPENDIX D - Laboratory Stands
Model A Laboratory Stand
This Lab Stand is provided with all standard Dial Reading Viscometers.
1
4
2
5
BROOKFIELD
LABORATORY
VISCOMETER
1
1
3
1
1
VS-21
VS-3
VS-1
VS-CRA-14A
JAM NUT
LEVELING SCREW
BASE
UPRIGHT ROD AND CLAMP ASSEMBLY
ITEM PART #
QTY.
DESCRIPTION
OPTIONALBLM-4E
*for use with Thermosel and Water Baths
ROD EXTENSION - 4” LONG *
2
3
4
5
VISCOMETER
HEAD CLAMP
KNOB
UP/DOWN
KNOB
3
TENSION
SCREW
Figure D-1
