4.2.5 Multiple sheets of paper are fed
4.2.6 Paper becomes wrinkled
<User Check>
Check that there is not too much paper set in each paper tray.
Check that the paper is set in each paper tray correctly.
Flip over the paper in each paper tray or rotate the paper 180°.
Check that the thickness of the paper is 60 to 120 g/m
2
for paper tray 1 to 5,
and 60 to 200 g/m
2
for the MP tray.
Flip through the paper and reset it in each paper tray.
Step Cause Remedy
1 Abrasion of a separation pad Replace the appropriate PF kit.
<User Check>
Check that the paper is set in each paper tray correctly.
Flip over the paper in each paper tray or rotate the paper 180°.
Adjust each paper guide according to each paper size.
Check that the thickness of the paper is 60 to 120 g/m
2
for paper tray 1 to 5,
and 60 to 200 g/m
2
for the MP tray.
Check that the paper is not damp.
Check that there is no dust stuck to the fuser unit.
Check that the type of paper is appropriate.
Step Cause Remedy
1 Eject motor failure Replace the eject motor.
2 Fuser unit failure Replace the fuser unit.
3
Damaged gears in the ejecting
system
Replace the main frame L ASSY.
