2-124
Confidential
4.14 Troubleshooting for Other Problems
4.14.1 Cannot print
4.14.2Cannot update firmware
4.14.3USB direct interface errors
<User Check>
Turn the power switch OFF and then ON again.
Check that the USB cable is connected to the host correctly.
Check that the LAN cable is connected to the host correctly.
Replace the USB cable.
Replace the LAN cable.
Check that the maximum printable page number has not been exceeded.
Check that the PC Print is not forbidden.
Check the print limit ID.
Check the network connection.
Check the relevant section in the Network Setting Guide.
Check that the print data is not damaged.
Install the latest main firmware.
Match the document size with the one specified in the driver.
Step Cause Remedy
1
Connection failure of the wireless
LAN connector
Reconnect the wireless LAN connector.
2 Wireless LAN PCB failure Replace the wireless LAN PCB.
3 Main PCB failure Replace the main PCB ASSY.
<User Check>
Make sure that there is no other function running.
Turn the power switch OFF and then ON again.
Step Cause Remedy
1
Firmware version does not match Reinstall the latest sub firmware and main
firmware in this order.
2 Main PCB failure Replace the main PCB ASSY.
<User Check>
Replace the USB flash memory.
Check that the extension of data in the USB flash memory is correct.
Check that an USB device not within the specifications is not connected.
Check that multiple USB devices are not connected.
Step Cause Remedy
1 USB host harness failure Replace the USB host harness.
2 USB host PCB failure Replace the USB host PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
