2-22
Confidential
3.2 Error Messages
Error message
Description
Error
codes
Refer
to:
First line Second line
Cartridge Error Put the Toner
Cartridge back in.
The new toner sensor could not
detect the new toner cartridge
correctly.
4F01 2-46
Cooling Down Wait for a while. The side thermistor of the fuser
unit or internal temperature sensor
detected a temperature higher
than the specified value.
6801 2-49
Cover is Open Close the ADF cover. The ADF cover sensor detected
that the ADF cover was open.
A400 2-74
Close the Back Cover
of the Machine.
The eject sensor detected that the
fuser cover was open.
6004 2-47
Close the Front Cover. The front cover sensor detected
that the front cover was open.
6001 2-47
Document Jam Clear the scanner jam,
then press Stop.
The document scanning position
sensor detected that the document
length was 90 cm or more during the
one-side scanning.
A200 2-73
The document scanning position
sensor has not detected the
document passing even after the
document has been fed for the
specified time.
A300 2-73
Drum ! Slide the Green tab on
Drum Unit.
Detected discharge that may be
attributable to dirty corona wire on
the drum unit.
6A00 2-50
Firmware Update You must update the
firmware.
Firmware version of the main PCB
is older than that of the TT and LT.
9400 2-71
Ignore Data Press Stop. Detected undecodable data during
printing. Received undecodable
PS data.
--- 4.14.1
Jam 2-sided Pull out the 2-sided
Tray at the back of the
machine and remove
the jammed paper.
The registration front sensor does
not detect paper pass within the
specified time after the first side was
printed in duplex printing mode.
7800 2-62
Jam Inside Open the Front Cover,
pull out the Drum Unit
completely and
remove the jammed
paper.
The eject sensor does not detect
paper pass after the registration rear
sensor detected the paper pass.
7000 2-51
Jam MP Tray Remove the jammed
paper from MP Tray
and press [Retry].
When feeding from the MP tray,
the registration rear sensor does
not detect paper pass within the
specified time after the registration
front sensor detected paper pass.
7200 2-52
