4.13.2 Fax cannot be received
4.13.3 Communication error occurs
<User Check>
Check that the line cord is inserted into the socket correctly.
Check that the receiving mode setting is correct.
Check that the handset is placed on the handset holder correctly.
Check that the receiver's machine works normally or the function you want to perform is
equipped with the receiver's machine.
Move the machine to the other place to check whether there is any noise source near
the machine.
Replace the telephone line.
Step Cause Remedy
1
Connection failure of modem flat
cable
Check the connection of the modem flat
cable, and reconnect it if necessary.
2 Modem PCB failure Replace the modem PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
<User Check>
Check whether there is any noise source near the machine.
Replace the telephone line.
Step Cause Remedy
1
Connection failure of modem flat
cable
Check the connection of the modem flat
cable, and reconnect it if necessary.
2 Modem PCB failure Replace the modem PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
