Confidential
5-4
Harness Routing
MP PE sensor ASSY
1
High-voltage PS PCB ASSY
Hook "A"
Hook "B"
MP feed frame
MP feed frame
Hole
Hook "A"
Machine top side
(Machine body upside down)
MP PE sensor ASSY
