Brother FAX-2800 User Manual

S - 4 SPECIFICATIONS
Parallel Interface
Interface Connector Printer Side: Amphenol FCN-685J036-L/X or equivalent
A shielded cable should be used.
USB (Universal Serial Bus) Interface
Pin Assignment
Pin No. Signal Direction Pin No. Signal Direction
1
DATA STROBE Input 19 0V(S.G.) -
2 DATA 1 Input 20 0V(S.G.) -
3 DATA 2 Input 21 0V(S.G.) -
4 DATA 3 Input 22 0V(S.G.) -
5 DATA 4 Input 23 0V(S.G.) -
6 DATA 5 Input 24 0V(S.G.) -
7 DATA 6 Input 25 0V(S.G.) -
8 DATA 7 Input 26 0V(S.G.) -
9 DATA 8 Input 27 0V(S.G.) -
10 ACKNLG Output 28 0V(S.G.) -
11 BUSY Output 29 0V(S.G.) -
12 PE Output 30 0V(S.G.) -
13 SLCT Output 31
INPUT PRIME Input
14 AUTO FEED Input 32 FAULT Output
15 N.C. - 33 N.C. -
16 0V (S.G.) - 34 N.C. -
17 0V (S.G.) - 35 N.C. -
18 +5V - 36 SLCT IN Input
Pin Assignment
Pin No. Signal
1 Vol (+5V)
2 - Data Serial Data -
3 + Data Serial Data +
4 Ground

Brother FAX-2800 Specifications

General

Automatic Document Feeder (ADF)	Yes
Modem Speed	33.6 Kbps
ADF Capacity	20 sheets
Paper Tray Capacity	250 sheets
Memory Transmission	Yes
Copier Function	Yes
Printing Technology	Laser
Transmission Speed	33.6 Kbps
Type	Plain Paper Fax
Resolution	600 x 600 dpi
Memory	512 KB
Fax Transmission Speed	6 seconds per page
Out-of-Paper Reception	Yes
Speed Dials	100
Paper Handling	Letter, Legal, A4
