3-5

Confidential

5. LUBRICATION

Fig. 3-3

Lubricating oil type

(Maker name)

Lubrication point Quantity of lubrication

FLOIL BG-10KS (Kanto Kasei) Fuser gear 67R/40R 3 places 1.5 to 2.0 mm dia. ball
