HL-5030/5040/5050/5070N SERVICE MANUAL
4-41
(5) Remove the three pan M3x6 screws.
(6) Remove the four cup S M3x6 Taptite screws, and then remove the main PCB ASSY.
Fig. 4-72
Main PCB ASSY
Taptite, cup S M3x6
Taptite, cup S
M3x6
Screw, pan M3x6
