HL-5030/5040/5050/5070N SERVICE MANUAL
4-47
(6) Remove the PE actuator and the CA actuator from the frame.
Fig. 4-82
(7) Remove the spring, extension P/R from the gear 63P/R.
(8) Remove the gear 63P/R.
(9) Remove the ground wire from the conductor bearing.
Fig. 4-83
Gear 63P/R
Spring, extension P/R
Ground wire
PE actuator
CA actuator
Frame
Hooks
Conductor Bearing
Hooks
