Power Cord Safety:
This product is equipped with a 3-wire grounded plug. This plug will only fit into a
grounded power outlet. This is a safety feature. DO NOT attempt to defeat the purpose
of the grounded plug.
DO NOT pull on the middle of the AC power cord; pulling on the middle may cause the
cord to separate from the plug. Doing this might cause an electrical shock.
Only use the power cord supplied with this product (for certain models only).
DO NOT use any undesignated cables (or optional devices). It may cause a fire or
injuries. Installation must be performed properly according to the user's guide.
This product should be positioned so that nothing pinches or constricts the power cord.
DO NOT allow anything to rest on the power cord.
DO NOT place this product where people may step on the cord.
DO NOT place this product in a position where the cord is stretched or strained, as it
may become worn or frayed.
DO NOT use the product if the power cord is frayed or damaged. Doing so may cause
an electrical shock or fire.
Brother strongly recommends that you DO NOT use any type of extension cord.
DO NOT drop any metallic hardware or any type of liquid on the power plug of the
product. It may cause an electrical shock or a fire.
DO NOT put a toner cartridge or a toner cartridge and drum unit assembly into a fire. It
could explode, resulting in injuries.
DO NOT use flammable substances, any type of spray, or an organic solvent/liquid
containing alcohol or ammonia to clean the inside or outside of the product. Doing so
could cause a fire or electrical shock. Instead, use only a dry, lint-free cloth.
DO NOT attempt to operate this product when a paper jam or stray pieces of paper are
inside the product. Prolonged contact of the paper with the fuser unit could cause a fire.
DO NOT use a vacuum cleaner to clean up scattered toner. Doing this might cause the
toner dust to ignite inside the vacuum cleaner, potentially starting a fire. Please carefully
clean the toner dust with a dry, lint-free soft cloth and dispose of it according to local
regulations.
