Brother HL-L2300D Service Manual

1-1
Confidential
CHAPTER 1 SUPPLEMENTAL
SPECIFICATIONS
1. GENERAL
The function comparative table for models as described in this Service Manual are shown below.
Model
HL-L2305W HL-L2300D HL-2260
HL-L2320D
HL-2260D
HL-L2321D
HL-L2315DW
HL-L2340DW
HL-L2360DN
HL-2560DN
HL-L2361DN
HL-L2360DW
HL-L2365DW
HL-L2366DW
Wired/
Wireless
LAN
Wired/
Wireless
N/A N/A N/A Wireless Wired
Wired/
Wireless
Duplex
printing
N/A

N/A

LCD

N/A N/A N/A

Model HL-L2305W HL-L2300D HL-2260
Warm-up time
From Sleep mode Less than 9 seconds at 73.4F (23°C)
From Power
OFF
 ON
Less than 26 seconds at 73.4F (23°C)
First print time
From Ready mode Less than 8.5 seconds at 73.4F (23°C)
From Sleep mode Less than 17.5 seconds at 73.4F (23°C)
CPU ARM9 266 MHz
Dimensions
(W x D x H)
Carton size 441 x 286 x 504 mm
(17.4 x 11.3 x 19.8 inch)
524 x 451 x 291 mm
(20.6 x 17.8 x 11.5
inch)
Machine size
356 x 360 x 183 mm (14.0 x 14.2 x 7.2 inch)
Weights
with Carton 7.7 kg / 17.0 lb 7.9 kg / 17.4 lb
(for the U.S.A.)
8.0 kg / 17.7 lb
(for Europe)
7.8 kg / 17.3 lb
without Carton
with toner/drum
6.6 kg / 14.6 lb 6.8 kg / 15.0 lb
(for the U.S.A.)
6.9 kg / 15.2 lb
(for Europe)
6.5 kg / 14.3 lb
without Carton nor
toner/drum
5.7 kg / 12.6 lb 5.9 kg / 13.0 lb
(Except for
Europe)
5.7 kg / 12.6 lb (for
Europe)
5.6 kg / 12.3 lb
Specifications are subject to change without notice.

Brother HL-L2300D Specifications

General

Color	No
N-up printing	2, 4, 6, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	6.5 ppm
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	1
Page description languages	GDI
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	210 x 297 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor family	ARM Cortex
Noise level (idle)	30 dB
Maximum internal memory	- MB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	45 dB
Display	LED
Certification	Nordic Swan
Display number of lines	1 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1080 W
Power consumption (off)	0.06 W
Power consumption (standby)	58 W
Power consumption (printing)	455 W
Power consumption (PowerSave)	5.4 W
Sustainability certificates	Blue Angel, ENERGY STAR
Minimum storage drive space	80 MB
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	441 mm
Package width	286 mm
Package height	504 mm
Package weight	8000 g
Cables included	AC

Weight and Dimensions

Depth	356 mm
Width	360 mm
Height	183 mm
