5-24
Confidential
1.3.14 Print test pattern (function code: 71)
<Function>
This function is used to print the test pattern to check whether the develop roller or exposure
drum is dirty or damaged.
<Operating Procedure>
(1) Press the [▲] or [▼] key in the initial state of maintenance mode to display
"MAINTENANCE 71" on the LCD, and press the [OK] key. "SELECT: A4" is displayed on
the LCD.
(2) Refer to the <Paper size> table, press the [▲] or [▼] key to select the paper size, and
press the [OK] key. "SELECT: PLAIN" is displayed on the LCD.
(3) Refer to the <Print specification> table, press the [▲] or [▼] key to select the media
specification, and press the [OK] key. "SELECT: SX" is displayed on the LCD.
(4) Refer to the <Print type> table, press the [▲] or [▼] key to select the print type, and
press the [OK] key. "SELECT: 1PAGE" is displayed on the LCD.
(5) Refer to the <Print page> table, press the [▲] or [▼] key to select the pages printing,
and press the [OK] key. "PRINTING" is displayed on the LCD, and printing test pattern
starts using the selected conditions.
(6) When printing is completed, "2D3S K" is displayed on the LCD, and it returns to the
printing pattern display. Press the [OK] key to perform this again.
(7) Press and hold the [Go] key, and the machine returns to the initial state of maintenance
mode.
<Paper size>
Note:
• If printing fails, printing is stopped with displaying any of the errors shown in the <Error
display> table. To retry printing, refer to the "Remedy" in the table to eliminate the error
cause, and press the [Go] key. "PRINTING" is displayed on the LCD, and the test
pattern is printed.
LCD Description
SELECT:A4 A4
SELECT:ISOB5 ISO B5
SELECT:JISB5 JIS B5
SELECT:A5 A5
SELECT:A5L A5L
SELECT:JISB6 JIS B6
SELECT:A6 A6
SELECT:EXECUTE Executive size
SELECT:LEGAL Legal size
SELECT:FOLIO Folio size
SELECT:HAGAKI Postcard size
SELECT:LETTER Letter
