Brother HL-L2300D - Main Components

2-8
Confidential
2.5 Main Components
Fig. 2-4
Paper tray
Duplex tray
Back cover
Outer chute ASSY
Front cover ASSY
Side cover R
Fuser cover
Inner chute ASSY
Side cover L
Top cover ASSY (LED models)Top cover ASSY (LCD models)
Fuser unit
LVPS shield plate cover
LVPS insulation
sheet
Low-voltage
power supply
PCB ASSY
Fan
High-voltage power
supply PCB ASSY
Air duct
Filter
Laser unit
Wireless LAN PCB
Roller holder ASSY
Main PCB ASSY
T1 clutch
Registration clutch
New toner sensor PCB ASSY
Motor drive sub ASSY
Fuser gear 67R/40R
Eject sensor PCB ASSY
Registration front/rear actuator holder ASSY
