5-8
Confidential
1.3.3 Set worker switches (WSW) and print worker switch setting data
(function code: 10, 11)
[1] Set worker switches (function code: 10)
<Function>
The worker switches shown in the table below can be used to set the function to satisfy
various requirements. These switch settings can be changed using the keys on the control
panel.
The worker switches are factory set to conform to the laws and regulations of the country the
machine is shipped to. Do not change these settings unless necessary.
WSW No. Function
WSW17 Selector 5
Change time display method
(American: MM/DD/YY or European: DD/MM/YY)
WSW47 Selector 8 Change USB High/Full Speed
WSW56 Selector 6 Change coverage type display
WSW56 Selector 7 Change ON/OFF setting for PCL Emulation
WSW59 Selector 1 Change ON/OFF setting for USB serial number sending
WSW63 Selector 1-2 Change printing speed
WSW63 Selector 3
Change time display method (Japanese: YY/MM/DD or others)
WSW63 Selector 4-7 Demo printing type
WSW63 Selector 8 Change ON/OFF setting for Israeli font support
WSW64 Selector 1-6 Language setting
WSW64 Selector 7-8 Default paper size
WSW65 Selector 1-2 Default media type
WSW65 Selector 3 Change ON/OFF setting for Bond Paper support
WSW65 Selector 4 Change ON/OFF setting for Postcard support
WSW65 Selector 6 Change ON/OFF setting for Label support
WSW78 Selector 1
Recording stop function when the drum reaches the end of life
