Brother HL-S7000DN Network User's Guide

Additional network settings from Windows
®
99
11
Network printing installation for Infrastructure mode when
using Vertical Pairing (Windows
®
7) 11
Windows
®
Vertical Pairing is a technology to allow your Vertical Pairing supported wireless machine to
connect to your Infrastructure network using the PIN Method of WPS and the Web Services feature. This also
enables the printer driver installation from the printer icon that is in the Add a device screen.
If you are in Infrastructure mode, you can connect your machine to the wireless network and then install the
printer driver using this feature. Follow the steps below:
Note
• If you have set your machine’s Web Services feature to Off, you must set it back to On. The default setting
of the Web Services for the Brother machine is On. You can change the Web Services setting by using
Web Based Management (web browser) or BRAdmin Professional 3.
• Make sure your WLAN access point/router includes the Windows
®
7 compatibility logo. If you are not sure
about the compatibility logo, contact your access point/router manufacturer.
• Make sure your computer includes the Windows
®
7 compatibility logo. If you are not sure about the
compatibility logo, contact your computer manufacturer.
• If you are configuring your wireless network using an external wireless NIC (Network Interface Card),
make sure the wireless NIC includes the Windows
®
7 compatibility logo. For more information, contact
your wireless NIC manufacturer.
• To use a Windows
®
7 computer as a Registrar, you need to register it to your network in advance. See the
instructions supplied with your WLAN access point/router.
a Turn on your machine.
b Set your machine in WPS mode (PIN Method).
For how to configure your machine to use the PIN Method see Configuration using the PIN Method of
WPS (Wi-Fi Protected Setup) uu page 24.
c Click the button and then Devices and Printers.
d Choose Add a device on the Devices and Printers dialog.
e Choose your machine and input the PIN which your machine has indicated.
f Choose the Infrastructure network that you want to connect to, and then click Next.
g When your machine appears in the Devices and Printers dialog, the wireless configuration and the
printer driver installation are successfully completed.

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
