Brother MFC-7440N - Adf

Ref. 2-11
Confidential
3.3 ADF
The following figure shows the document feeding paths.
■ ADF part
Fig. Ref. 2-12
Pressure roller
Document front actuator
Document rear actuator
Pressure roller
Pressure roller
Separation roller shaft ASSY
ADF motor
Ejection roller
Document cover
LF roller
