Brother MFC-J1300DW User Manual

Home > Security > Network Security Features > Secure Function Lock 3.0 > Configure Secure Function
Lock 3.0 Using Web Based Management
Configure Secure Function Lock 3.0 Using Web Based Management
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If the machine prompts you for a password, type it, and then click
.
4. Click the Administrator tab.
5. Click the Restriction Management or User Restriction Function menu in the left navigation bar.
6. Select Secure Function Lock.
7. Click Submit.
8. Click the Restricted Functions menu in the left navigation bar.
9. In the User List / Restricted Functions field, type a group name or user name.
10. In the Print and the other columns, select a check box to allow or clear a check box to restrict the function
listed.
11. To configure the maximum page count, select the On check box in the Page Limits column, and then type
the maximum number in the Max. Pages field.
12. Click Submit.
13. Click the User List menu in the left navigation bar.
14. In the User List field, type the user name.
15. In the PIN Number field, type a four-digit password.
16. To register the user's Card ID, type the card number in the Card ID (NFC ID) field (Available only for certain
models) .
17. Select User List / Restricted Functions from the drop-down list for each user.
18. Click Submit.
Related Information
• Secure Function Lock 3.0
Related Topics:
• Register Your Machine with Google Cloud Print Using Web Based Management
363

Brother MFC-J1300DW Specifications

General

N-up printing	2, 4, 9, 16
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Duplex printing mode	Auto/Manual
N-in-1 print function	Yes
Print speed (ISO/IEC 24734) mono	12 ipm
Print speed (ISO/IEC 24734) color	10 ipm
Time to first page (black, normal)	8 s
Time to first page (color, normal)	8.5 s
Duplex print speed (ISO/IEC 24734) mono	3 ipm
Print speed (black, normal quality, A4/US Letter)	- ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
Duplex copy speed (black, US Letter)	2.5 ppm
Faxing	Color faxing
Fax memory	180 pages
Modem speed	14.4 Kbit/s
Fax speed dialing (max numbers)	100
Scan to	E-mail, FTP, File, Image, OCR, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	30 bit
Maximum scan area	216 x 297 mm
Output color depth	24 bit
Image formats supported	JPEG, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	5000 pages per month
Recommended duty cycle	50 - 1500 pages per month
Page description languages	GDI
Display	LCD
Control type	Touch
Product color	White
Display diagonal	2.67 \
Market positioning	Home & office
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSec, LEAP, PEAP, SMTP-AUTH, SNMPv3, SSID, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Ethernet LAN data rates	10, 100 Mbit/s
Online services supported	Box, Dropbox, Evernote, OneDrive, OneNote
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port9100, IPP, FTP/FTPs Client FTP Server, SNMPv1/v2c/v3, TFTP server, SMTP Client, ICMP, Web Services (Print/ Scan), CIFS Client, SNTP Client, LDAP, HTTP Server
Supported network protocols (IPv6)	NDP, RA, mDNS, LLMNR Responder, DNS Resolver, LPR/LPD, Custom Raw Port/ Port9100, IPP, FTP/FTPs Client FTP, SNMPv1/v2c/v3, TFTP server, Web Services (Print/Scan), SMTP Client, CIFS Client, SNTP Client, LDAP, ICMPv6, HTTP Server
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Internal memory	128 MB
Compatible memory cards	MMC, MMC Mobile, MMC+, SD, SDHC, SDXC
Sound pressure level (copying)	50 dB
Power consumption (off)	0.2 W
Power consumption (sleep)	1.3 W
Power consumption (standby)	4 W
Power consumption (average operating)	20 W
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Paper input type	Paper tray
Total input capacity	150 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Bundled software	Brother iPrint&Scan, Nuance PaperPort 14 SE, Brother Control Centre 4
Envelopes sizes	C5, Com-10, DL, Monarch
Photo paper sizes	9x13 cm
Custom media width	148 - 216 mm
Custom media length	148 - 355 mm
Duplex media weight	64 - 105 g/m²
Paper tray media types	Glossy paper, Photo paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Index card
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Glossy paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Printer management	BRAdmin Light

Weight and Dimensions

Depth	341 mm
Width	435 mm
Height	195 mm
