Option Description
the SA, is included in the Authentication Header (AH) and
Encapsulating Security Payload (ESP) header.
These settings are necessary when Custom is selected for Use
Prefixed Template, and Manual is selected for Internet Key
Exchange (IKE).
Enter the In/Out values. (3-10 characters)
Encapsulating Security • Protocol
Select ESP or AH.
- ESP is a protocol for carrying out encrypted communication
using IPsec. ESP encrypts the payload (communicated
contents) and adds additional information. The IP packet is
comprised of the header and the encrypted payload, which
follows the header. In addition to the encrypted data, the IP
packet also includes information regarding the encryption
method and encryption key, the authentication data, and so
on.
- AH is part of the IPsec protocol that authenticates the
sender and prevents manipulation of the data (ensures the
completeness of the data). In the IP packet, the data is
inserted immediately after the header. In addition, the
packets include hash values, which are calculated using an
equation from the communicated contents, secret key, and
so on, in order to prevent the falsification of the sender and
manipulation of the data. Unlike ESP, the communicated
contents are not encrypted, and the data is sent and
received as plain text.
• Encryption
Select DES, 3DES, AES-CBC 128, or AES-CBC 256.
• Hash
Select None, MD5, SHA1, SHA256, SHA384, or SHA512. None
can be selected only when ESP is selected in Protocol.
• SA Lifetime
Specify the IKE SA lifetime.
Type the time (seconds) and number of kilobytes (KByte).
• Encapsulation Mode
Select Transport or Tunnel.
• Remote Router IP-Address
Type the IP address (IPv4 or IPv6) of the remote router. Enter this
information only when the Tunnel mode is selected.
SA (Security Association) is an encrypted communication
method using IPsec or IPv6 that exchanges and shares
information, such as the encryption method and encryption key,
in order to establish a secure communication channel before
communication begins. SA may also refer to a virtual encrypted
communication channel that has been established. The SA
used for IPsec establishes the encryption method, exchanges
the keys, and carries out mutual authentication according to the
IKE (Internet Key Exchange) standard procedure. In addition,
the SA is updated periodically.
Related Information
• Configure an IPsec Template Using Web Based Management
412
