Confidential
2-36
■ Error Code 3C00
Abnormal stop of head/carriage unit being driven.
- Caused by paper jam when ink is discharging.
< User Check >
- Remove the jammed paper in platen part.
■ Error Code 3E00
Defective occurs in the ASF motor, carriage motor or paper feed motor.
Step Cause Solution
1
Foreign materials in the engine unit
Remove foreign materials.
2 CR encoder strip stained Clean the CR encoder strip.
3 CR encoder strip defective Replace the CR encoder strip.
4 CR encoder sensor defective Replace the carriage PCB ASSY.
5 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Foreign materials in the
recording paper path
Remove foreign materials.
2 Foreign materials in the
maintenance unit
Remove foreign materials.
3 Foreign materials around
paper feed roller belt
Remove foreign materials.
4 Foreign materials around
paper ejection roller belt
Remove foreign materials.
5
Foreign materials in the engine unit
Remove foreign materials.
6 Maintenance unit not mounted
in place
Set the maintenance unit into place.
7
Flushing box not mounted in place
Set the flushing box into place.
8
CR guide rail not mounted in place
Set the CR guide rail into place.
9 Platen not mounted in place Set the platen into place.
10 Head/carriage unit not
mounted in place
Set the head/carriage unit into place.
11 CR encoder strip defective Replace the CR encoder strip.
12 PF encoder disk defective Replace the PF encoder disk.
13 PF encoder sensor defective Replace the PF encoder sensor.
14 CR encoder sensor defective Replace the carriage PCB ASSY.
15 Carriage motor defective Replace the carriage motor.
16 Paper feed motor defective Replace the paper feed motor.
17 ASF motor defective Replace the maintenance unit.
18 Main PCB defective Replace the main PCB.
To Next Page
