Brother MFC-J430w User Guide

Routine maintenance
29
A
Packing and shipping
the machine
A
When you transport the machine, use the
packing materials that came with your
machine. Follow the instructions below to
correctly package your machine. Damage
caused to your machine during transit may
not be covered by your warranty.
IMPORTANT
It is important to allow the machine to
“park” the print head after a print job.
Listen carefully to the machine before
unplugging it to make sure that all
mechanical noise has stopped. Not
allowing the machine to finish this process
may lead to print problems and possible
damage to the print head.
a Open the ink cartridge cover.
b Remove all four ink cartridges. Press
the ink release lever above each
cartridge to release it.
(uuBasic User’s Guide: Replacing the
ink cartridges)
c Install the orange protective part and
then close the ink cartridge cover.
IMPORTANT
• Make sure the plastic tab on the right side
of the orange protective part (1) clicks
securely into place (2).
• If you are not able to find the orange
protective part, ship the machine without
it. DO NOT install the ink cartridges as an
alternative before shipping.
d Lift the machine from the front and hook
the tab of the orange protective part into
the keyed opening (1) on the bottom of
the paper tray. Then latch the protective
part over the raised portion of the paper
tray (2).
1
2
1
2

Brother MFC-J430w Specifications

General

Maximum print size	210 x 297 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Index card
ISO A-series sizes (A0...A9)	A4, A5, A6
Photo paper sizes (imperial)	4x6, 5x7, 5x8, 8.5x11 \
Borderless printing media sizes	4x6, 5x7, A4, A6, Index card, Letter
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
All-In-One-multitasking	Yes
Number of print cartridges	4
Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	26 ppm
Processor family	RISC
Sound pressure level (printing)	50 dB
Paper input type	Cassette
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	15 sheets
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, TKIP, WEP, WPA-PSK, WPA-TKIP, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	5.5 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	19 W
Operating temperature (T-T)	68 - 78.8 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Display	LCD
Product color	Black
Display diagonal	1.9 \
Market positioning	Home & office
Scan speed	3.37 sec/page
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (color, normal)	24 s
Copy speed (black, normal quality, A4)	22 cpm
Copy speed (color, normal quality, A4)	20 cpm
Scan to	E-mail, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	36 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	203 x 392 DPI
Fax transmission speed	7 sec/page
Fax speed dialing (max numbers)	40
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Package weight	10130 g

Weight and Dimensions

Depth	378 mm
Width	405 mm
Height	180 mm
