Page #33 background imageLoading...
Page #33 background image
Home > Download, Print, and Save > Download and Print Documents Using Brother Web
Connect > Download and Print Using Picasa Web Albums
, Flickr
®
, Facebook, Google Drive
, Evernote
®
,
Dropbox, OneDrive
®
and Box
Download and Print Using Picasa Web Albums
, Flickr
®
, Facebook,
Google Drive
, Evernote
®
, Dropbox, OneDrive
®
and Box
Related Models: DCP-J562DW/DCP-J785DW/MFC-J680DW/MFC-J880DW/MFC-J885DW/MFC-J985DW
1. Press d or c to display [Web].
Press [Web].
If information regarding the Internet connection appears on the machine's LCD, read the information
and press [OK].
Occasionally, updates or announcements about Brother Web Connect's features will appear on the
LCD. Read the information, and then press [OK].
2. Press a or b to display the service that hosts the document you want to download and print.
Press the service name.
3. Do one of the following:
To log on to the service, press a or b to display your account name, and then press it. If the PIN entry
screen appears, enter the four-digit PIN and press [OK].
To access the service as a guest user, press a or b to display [Use as a GuestUser], and then press
it. When the information regarding access as a guest user appears, press [OK].
4. Press a or b to display [Download: Print].
Press [Download: Print].
If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Picasa Web Albums
and Flickr
®
:
- To download your own documents from the service, press [Your album].
- To download other users’ documents from the service, press [Other user's album], and then
enter or select the account name of the user whose documents you want to download.
5. Press a or b to display the desired album, and then press it.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select [See Unsorted Files] or [See UnsortedPhotos] to select documents. You cannot
download documents from other users if they are not saved in an album.
6. Press the thumbnail of the document you want to print. Confirm the document on the LCD and press [OK].
Select additional documents to print (you can select up to 10 documents).
7. When finished, press [OK].
8. When the Print Settings screen appears on the LCD, do one of the following:
To continue without changing the print settings, press [OK].
Select the print settings you want to change, and then press [OK].
Option Description
Print Quality
Select the print quality.
28

Table of Contents

Other manuals for Brother MFC-J480DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J480DW and is the answer not in the manual?

Brother MFC-J480DW Specifications

General IconGeneral
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal1.8 \
Market positioningHome & office
Mac operating systems supportedMac OS X 10.8 Mountain Lion, Mac OS X 10.0 Cheetah, Mac OS X 10.9 Mavericks
Other operating systems supportedAndroid, iOS, Windows Phone
Server operating systems supportedWindows Server 2012 R2 x64, Windows Server 2003, Windows Server 2008 R2 x64, Windows Server 2012 x64, Windows Server 2008 x64, Windows Server 2003 x64, Windows Server 2008
Windows operating systems supportedWindows 7 Enterprise, Windows 8, Windows Vista Home Premium, Windows 10 Education, Windows 7 Enterprise x64, Windows 8 Enterprise, Windows Vista Home Premium x64, Windows 10 Education x64, Windows 7 Home Basic, Windows 8 Enterprise x64, Windows Vista Ultimate, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 8 Pro, Windows Vista Ultimate x64, Windows 10 Enterprise x64, Windows 7 Home Premium, Windows 8 Pro x64, Windows XP Home, Windows 10 Home, Windows 7 Home Premium x64, Windows 8 x64, Windows XP Home x64, Windows 10 Home x64, Windows 7 Professional, Windows 8.1, Windows Vista Business, Windows XP Professional, Windows 10 Pro, Windows 7 Professional x64, Windows 8.1 Enterprise, Windows Vista Business x64, Windows XP Professional x64, Windows 10 Pro x64, Windows 7 Starter, Windows 8.1 Enterprise x64, Windows Vista Enterprise, Windows 7 Starter x64, Windows 8.1 Pro, Windows Vista Enterprise x64, Windows 7 Ultimate, Windows 8.1 Pro x64, Windows Vista Home Basic, Windows 7 Ultimate x64, Windows 8.1 x64, Windows Vista Home Basic x64
Sustainability certificatesNordic Swan Ecolabel, ENERGY STAR
Ethernet LANNo
Wi-Fi standards802.11g, 802.11b, Wi-Fi 4 (802.11n)
Security algorithmsWPA2-AES, SSID, 64-bit WEP, WPA2-PSK, 128-bit WEP, WPS, WPA-AES, WPA-PSK, WPA-TKIP
Online services supportedBox, Facebook, OneDrive, Dropbox, Flickr, OneNote, Evernote, Google Drive, Picasa
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Mopria Print Service, Google Cloud Print
Print technologyInkjet
Maximum resolution1200 x 6000 DPI
Duplex printing modeAuto
Print speed (ISO/IEC 24734) mono11 ipm
Print speed (ISO/IEC 24734) color6 ipm
Print speed (black, normal quality, A4/US Letter)27 ppm
Print speed (color, normal quality, A4/US Letter)23 ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 2400 DPI
Maximum number of copies99 copies
Copy speed (black, normal quality, A4)6 cpm
Copy speed (color, normal quality, A4)3 cpm
Scan toImage, Fax, E-mail, File, OCR
Scan driversICA, TWAIN, WIA
Grayscale levels256
Input color depth30 bit
Maximum scan areaA4 (210 x 297) mm
Output color depth24 bit
Image formats supportedBMP, JPG, PNG, TIF
Maximum scan resolution19200 x 19200 DPI
Document formats supportedPDF
FaxingColor faxing
Fax memory170 pages
Modem speed14.4 Kbit/s
Fax resolution (black)203 x 203 DPI
Fax speed dialing (max numbers)40
Printing colorsBlack, Cyan, Magenta, Yellow
Number of print cartridges4
Envelopes sizesC5, Com-10, DL, Monarch
Paper tray media typesGlossy paper, Plain paper, Coated paper, Recycled paper
Non-ISO print media sizes2L, Executive (184 x 267mm), Letter (media size), Index card, L
ISO A-series sizes (A0...A9)A5, A6, A4
Borderless printing media sizes2L, 10x15, Letter, A4, Index card, L, A6
Maximum ISO A-series paper sizeA4
Direct printing-
Standard interfacesUSB 2.0, Wireless LAN
Package depth249 mm
Package width477 mm
Package height456 mm
Package weight10100 g
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.2 W
Power consumption (ready)3.5 W
Power consumption (average operating)19 W
Noise level50 dB
Bundled softwareBrother ControlCenter 2 Brother ControlCenter 4 Nuance Paperport 14 SE Brother MFL-Pro Suite
Total input capacity100 sheets
Total output capacity50 sheets
Auto document feeder (ADF) input capacity20 sheets
Internal memory128 MB
Storage temperature (T-T)20 - 33 °C
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth341 mm
Width400 mm
Height172 mm
Weight8300 g
