Brother MFC-J6545DW User Manual

Confidential
2-63
■ Paper jam around the platen
< User Check >
- Check that recording paper is loaded correctly in the tray.
- Adjust the paper guide to match the recording paper size.
- Check that the paper smaller than the specified size is not loaded.
- Check thickness of recording paper is within tolerance of each type.
- Clean the related rollers.
Step Cause Solution
1 Foreign materials in the
recording paper path
Remove foreign materials.
2 CR encoder strip stained Clean the CR encoder strip.
3
PF encoder disk stained Replace the PF encoder disk.
4 CR encoder strip out of place Set the CR encoder strip into place.
5 Platen foam drift Set the platen foam into place.
6 Bank ASSY out of place Set the bank ASSY into place.
7 Head/carriage unit head
unlocked
Set the head lock in lock position.
8 Switchback inner paper guide
not mounted in place
Set the switchback inner paper guide into place.
9 Switchback outer paper guide
not mounted in place
Set the switchback outer paper guide into place.
10
Switchback roller belt out of place Set the switchback roller belt into place.
11
Paper ejection roller belt out of place Set the paper ejection roller belt into place.
12
CR guide rail not mounted in place Set the CR guide rail into place.
13
Corrugate plate not mounted in
place
Set the corrugate plate into place.
14
Platen ASSY not mounted in place Set the platen ASSY into place.
15
Platen spring not mounted in place Set the platen spring into place.
16 CR encoder strip defective Replace the CR encoder strip.
17 PF encoder disk defective Replace the PF encoder disk.
18 PF encoder sensor defective Replace the PF encoder sensor PCB ASSY.
19 DX paper guide ASSY not
mounted in place
Set the DX paper guide ASSY into place.
20 Platen ASSY damaged,
broken
Replace the platen ASSY.
21 Registration sensor PCB
defective
Replace the registration sensor PCB ASSY.
22 Paper width sensor defective Replace the carriage PCB ASSY.
23 Main PCB defective Replace the main PCB.

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
