1.3.34 Assurance Mode Switch Setting (Maintenance mode 88)
< Function >
When the machine does not function normally because the usage environments or
operating conditions are not usual, the assurance mode switches provide workarounds
to make the machine usable by changing the machine settings to untypical ones.
The machine incorporates seven assurance mode switches (AMS01 through AMS07)
that are firmware switches just as the ones described in “1.3.5 Worker Switch Setting
and Printout (Maintenance modes 10 and 11)” in this chapter.
The user is allowed to access the assurance mode switches under the guidance of
service personnel (e.g., by telephone).
The details about AMS01 through AMS07 are described on the next page.
< Operating Procedure >
(1) Press the 8 key twice in the initial stage of the maintenance mode.
The machine displays "AMS00" on the LCD and becomes ready to accept an
assurance mode switch number.
(2) Enter the desired number from the assurance mode switch numbers (01 through
07).
The following appears on the LCD:
Selector 1 Selector 8
↓ ↓
AMSXX = 0 0 0 0 0 0 0 0
(3) Use the ◄ or ► key to make the selector you want to change blink.
(4) Enter the desired number (0 or 1)using the 0 and 1 keys.
(5) Press the SET key. This operation saves the newly entered selector values onto
the EEPROM and readies the machine for accepting an assurance mode switch
number.
(6) Repeat steps (2) through (5) until the modification for the desired assurance mode
switches is completed.
(7) Press the X key to return the machine to the initial stage of the maintenance mode.
Notes: - To cancel this operation and return the machine to the initial stage of the
maintenance mode during the above procedure, press the X key.
- If there is a pause of more than one minute after a single-digit number is
entered for double-digit assurance mode switch numbers, the machine will
automatically return to the initial stage of the maintenance mode.
- Initializing the EEPROM with Maintenance mode 01 or 91 initializes the AMS
switch settings.

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
