Confidential
Preface
This Service Manual is intended for use by service personnel and details the specifications,
construction, and maintenance for the Brother machines noted on the front cover. It includes
information required for troubleshooting and service--disassembly, reassembly, and lubrication--so that
service personnel will be able to understand equipment function, repair the equipment in a timely
manner and order spare parts as necessary.
To perform appropriate maintenance so that the machine is always in the best possible condition for the
customer, service personnel must adequately understand and apply this manual.
The table below shows the functional comparison between the models covered by this manual.
HL-
J6000DW
HL-
J6100DW
HL-
T4000DW
MFC-
J3530DW
MFC-
J3930DW
MFC-
J6530DW
MFC-
J6535DW
Scan --- --- --- Simplex Duplex Simplex Simplex
LCD 2.7 inch 2.7 inch 2.7 inch 2.7 inch 3.7 inch 2.7 inch 3.7 inch
Manual Feed
Slot
--- --- --- √ --- √ ---
MP Tray √√√--- √ --- √
Lower Tray √√--- --- √ --- ---
3rd Tray --- √ --- --- --- --- ---
NFC √√--- --- √ --- ---
Document
Size Sensor
--- --- --- --- --- --- √
Paper
Remaining
Sensor
√√--- --- --- --- ---
Ink Cartridge Simple Simple --- Regular Regular Regular Regular
Ink Tank --- --- √ --- --- --- ---
MFC-
J6545DW
MFC-
J6730DW
MFC-
J6930DW
MFC-
J6935DW
MFC-
J6945DW
MFC-
J6947DW
MFC-
T4500DW
Scan Simplex Simplex Duplex Duplex Duplex Duplex Simplex
LCD 3.7 inch 2.7 inch 3.7 inch 3.7 inch 3.7 inch 3.7 inch 2.7 inch
Manual Feed
Slot
--- √ --- --- --- --- ---
MP Tray √ --- √√√√√
Lower Tray --- √√√√√---
3rd Tray --- --- --- --- --- √ ---
NFC --- --- √√√√---
Document
Size Sensor
√ --- --- √√√---
Paper
Remaining
Sensor
--- --- --- √√√---
Ink Cartridge Simple Regular Regular Regular Simple Simple ---
Ink Tank --- --- --- --- --- --- √

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
