Brother MFC-J6545DW User Manual

Confidential
2-12
Error
Code
Contents
Refer to
page:
2A00 No black ink cartridge loaded.
- Detected by the ink cartridge detection sensor.
2-32
2A01 No yellow ink cartridge loaded.
- Detected by the ink cartridge detection sensor.
2-32
2A02 No cyan ink cartridge loaded.
- Detected by the ink cartridge detection sensor.
2-32
2A03 No magenta ink cartridge loaded.
- Detected by the ink cartridge detection sensor.
2-32
2B00 Black ink cartridge ink remaining counter error 2-32
2B01 Yellow ink cartridge ink remaining counter error 2-32
2B02 Cyan ink cartridge ink remaining counter error 2-32
2B03 Magenta ink cartridge ink remaining counter error 2-32
2E00 Cannot communicate with ink cartridge IC chip (machine body side.) 2-33
2F00 Ink cartridge cover sensor detects opened cover state. 2-33
3000 Carriage does not move.
- Detected by the CR encoder sensor.
2-33
3100 Carriage cannot detect origin.
- Detected by the CR encoder sensor.
2-34
3200 Head capping is unable. 2-34
3500 Abnormal stop of head/carriage unit being driven
- Causes other than paper jam when ink is not discharging
2-35
3800 Abnormal stop of head/carriage unit being driven
- Caused by paper jam when ink is not discharging
2-35
3B00 Abnormal stop of head/carriage unit being driven
- Causes other than paper jam when ink is discharging
2-35
3C00 Abnormal stop of head/carriage unit being driven
- Caused by paper jam when ink is discharging
2-36
3E00 Defective occurs in the ASF motor, carriage motor or paper feed motor. 2-36
3F00 Carriage motor cannot stop. 2-37
4000 Casing internal thermistor defective
- Casing internal thermistor detects -20 degree-C or less, or 80 degree-C
or more when power is ON.
2-37
4200 Head voltage does not turn OFF. 2-37
4300 Head thermistor defective
- Head thermistor detects -20 degree-C or less, or 80 degree-C or more
when power is ON.
2-38
4400
Head driver IC detects abnormal temperature during operation or stand-by. 2-38
4600 Purge count or flushing count overflown. 2-38
4800 Head flat cable detected to be not correctly inserted. 2-38
4900 Head voltage does not raise. 2-39
4C00 ASIC thermistor error
- The ASIC thermistor detected a temperature of -21 degree-C or less, or
125 degree-C or greater, when the machine was turned on.
2-39

Brother MFC-J6545DW Specifications

General

Type	all in one, fax
Color	white/gray, white
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	350
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
First Page Print Time	6 seconds
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	letter-size glossy inkjet paper; 4" x 6" glossy photo paper; letter-size multi-purpose paper
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Duplex Scan	no
Max Copies	999
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3037bk, lc3037c, lc3037m, lc3037y, lc3039bk, lc3039c, lc3039m, lc3039y
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, ethernet, google cloud print, mopria print service, usb 2.0, wi-fi, wi-fi direct
Mobile Devices Connection	yes

Weight and Dimensions

Depth	22.6 inches
Height	12.2 inches
Width	22.6 inches
Net Weight	44.3 pounds
