5.1.3 List of Maintenance-mode Functions
Maintenance-mode Functions
Function
Code
Function
Reference
Section (Page)
01
EEPROM Parameter Initialization 5.1.4.1 (5-5)
02
Creating of Head Calibration Data and Writing it into Flash ROM 5.1.4.2 (5-6)
05
Printout of Scanning Compensation Data 5.1.4.3 (5-9)
08
ADF Performance Test 5.1.4.4 (5-11)
09
Printout of Nozzle Test Pattern 5.1.4.5 (5-12)
10
Firmware Switch Setting 5.1.4.6 (5-14)
11
Printout of Firmware Switch Data 5.1.4.6 (5-15)
12
Operational Check of LCD 5.1.4.7 (5-17)
13
Operational Check of Control Panel PCB (Check of Keys) 5.1.4.8 (5-18)
28
Updating of Firmware Using an External Memory 5.1.4.9 (5-19)
32
Sensor Operational Check 5.1.4.10 (5-20)
46
Backup of Machine Information 5.1.4.11 (5-22)
52
Setting of Country/Language 5.1.4.12 (5-24)
53
Transfer of Received FAX Data and Log Information 5.1.4.13 (5-25)
54
Fine Adjustment of Scanning Position 5.1.4.14 (5-28)
55
Acquisition of White & Black Level Data and CIS Scanner Area
Setting
5.1.4.15 (5-29)
58
Updating of Paper Feeding Correction Value 5.1.4.16 (5-30)
59
Checking of CIS Travel 5.1.4.17 (5-37)
61
Printout of PRN/JPEG Files in Memory Card 5.1.4.18 (5-38)
63
Travel Check of the Head/Carriage Unit and Initial Setup Mode 5.1.4.19 (5-40)
65
Alignment of Vertical Print Lines in Monochrome 5.1.4.20 (5-41)
66
Margin Adjustment in Borderless Printing 5.1.4.21 (5-43)
68
Updating of Head Property Data and Backup/Restoration of Head
Calibration Data
5.1.4.22 (5-46)
69
Traveling Speed Check of Head/Carriage Unit 5.1.4.23 (5-48)
70
Cleaning of Leveler Roller (LR) ASSY 5.1.4.24 (5-49)
74
EEPROM Customizing 5.1.4.25 (5-50)
75
Travel of Head/Carriage Unit (for removing paper particles and
dust accumulated on the maintenance unit)
5.1.4.26 (5-53)
76
Purge Operation 5.1.4.27 (5-54)
77
Print of the Equipment’s Log 5.1.4.28 (5-57)
78
Adjustment of Touch Panel 5.1.4.29 (5-60)
80
Display of the Equipment's Log 5.1.4.30 (5-62)
82
Equipment Error Code Indication 5.1.4.31 (5-67)
87
Output of Transmission Log to the Telephone Line 5.1.4.32 (5-67)
88
Assurance Mode Switch Setting 5.1.4.33 (5-68)
91
EEPROM Parameter Initialization (except the telephone number
storage area)
5.1.4.1 (5-5)
99
Exit from the Maintenance Mode ------ (5-2)
(Menu + #,
2, 7, 9, 0, 0)
Cancellation of the Pin TX Lock Mode (Not applicable to
Japanese and U.S.A. models)
5.2.1 (5-75)
: A function that the end user can use. (Refer to Section 5.1.1.)
