Brother MFC-L6900DW

To Next Page

To Previous Page

3-18

Confidential

Speaker unit, Modem (Main PCB side)

Harness colors are subject to change for some reason.

Modem flat cable

Modem FG harness L (BK)

Modem FG harness R (GR)

Speaker harness

(RD, BK)
