Fig. 3-73

Assembling Note:

• Fold the modem flat cable at the positions shown in the figure below.

Mountain fold

Valley fold

90±1

Main PCB

side

Modem

PCB side

45° 45°

96

141

170

Reinforcing plate

Conductor
