Brother MFC-L6902DW User Manual

3-8
Confidential
 MP damper spring
Fig. 3-6
 Idle gear 50 Z18M10 (Models with 520-sheet only)
Fig. 3-7
Lubricating oil type
(Maker name)
Lubrication point Quantity of lubrication
HANARL BDX-313A
(Kanto Kasei)
MP damper spring Apply to
the internal
diameter.
Apply with brush more
than once.
Idle gear 50 Z18M10

Brother MFC-L6902DW Specifications

General

Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Display	4.85" Color Touchscreen
Paper Input Capacity	570 sheets
ADF Capacity	80 sheets
Functions	Print, Copy, Scan, Fax
Processor	800 MHz
Memory	1 GB
Scan Resolution	1200 x 1200 dpi
Fax Speed	33.6 Kbps
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	AirPrint, Google Cloud Print, Mopria, Brother iPrint&Scan
Print Speed	Up to 52 ppm - B/W (letter A)
