SPECIFICATIONS
ENGINE
1200 4-TEC
Engine type
Rotax 1203, liquid cooled, 4-Stroke, D.O.H.C.
with balancer shaft, dry sump
Cylinders
3
Displacement 1 170.7 cm³ (71.44 in³)
Bore 91 mm (3.58 in)
Stroke 60 mm (2.36 in)
Maximum horsepower engine RPM 7800 RPM
Fuel injection system Multi point EFI, 52 mm heated throttle body
Exhaust system Exhaust pipe, muffler
Engine oil
XPS 4-STROKE SYNTHETIC OIL (F) (P/N 619 590
114)
or SAE 0W 40 API SM or SN synthetic oil
Engine oil tank capacity Oil change with filter: 3.5 L (3.7 qt (U.S. liq.))
Coolant
Ethyl glycol/water mix (50% coolant, 50%
distilled water). Use
LONG LIFE ANTIFREEZE(F)
(P/N 619 590 204)
or coolant specifically
designed for aluminum engines
Cooling system capacity 5.5 L (5.81 qt (U.S. liq.))
Recommended fuel type
Regular unleaded (fuel containing maximum
10% ethanol)
Minimum octane 95 (fuel which may contain up to 10% MAX ethanol)
Fuel tank capacity (SAE J288a) 39 L (10.3 U.S. gal.)
______________
129
