CONTROLS, INSTRUMENTS AND EQUIPMENT
fmo2009-004-093_a
TYPICAL
1. Mountain strap
WARNING
This strap is not for towing, lifting
or other purpose than temporary
use as a grab handle when a lever-
age is needed at very low speeds.
17) Storage Compartment
The storage compartment is located
behind the driver's seat.
WARNING
The storage compartment must
be properly latched and must not
contain any sharp or breakable ob-
jects.
To open the lid, pull and hold the rubber
tab sideways, then lift the RH side of
the lid or passenger seat if installed.
fmo2009-004-024_a
Step 1: Pull rubber t ab
Step 2: Lift RH side
To clos e lid, sim ply push it down until it
latches.
In addition, when passenger seat is in-
stalled, hook the retaining strap to the
rear bumper as shown.
fmo2010-002-012_a
1. Re taining strap
2. Rear bumper
CAUTION When closing lid
with the pas senger seat installed,
secure with the retaining strap.
Battery
Battery is located in storage box under
passenger seat. To get access to bat-
tery push battery cover notches both
sides of cover and remove it
