i18 User Manual V11 120219 Page 18 of 19
15.4. Error Codes
ERROR
PROBLEM
CAUSE
SOLUTION
“E0” is displayed
Proximity Sensor
open all time
Piston has been open to long
Return the Dispense head spigot
piston
Something too close proximity Sensor
Remove object blocking red
sensor
Proximity Sensor Broken
change new proximity Sensor
“E1” is displayed
Motors
Hardness setting too high
Reduce hardness setting
Running Capacitor to low
Check or replace run capacitor
Motor/s not reading resistance
Change Motor/s
Voltage More than 250V
Check incoming voltage
“E2” is displayed
High cut out switch
pressure
Cooling of machine has been restricted
Machine must be installed no
closer than 15cm to any wall in
order to allow free air circulation
around the condenser
Condenser dirty
Clean Condenser
Check fan and capacitor
Change fan/or capacitor
Fan Broken
Change Fan
Pressure Switch Broken
Change Pressure Switch
“E3” is displayed
Power supply
protection
The supply voltage is too high or too low
Check Power and Voltage
“E4” is displayed
Hopper temperature
sensor error
The hopper temp sensor is shorted out or has an
open circuit
Change Hopper temperature
sensor
“E5” is displayed
Freezer cylinder
sensor error
The freezer cylinder temp sensor is shorted out or
has an open circuit
Change Freezer cylinder sensor
“E7” is displayed
Compressor error
inadequate ventilation around machine
Machine must be installed no
closer than 15cm to any wall in
order to allow free air circulation
around the condenser
hardness setting too high
Reduce hardness setting
low on refrigerant
Check refrigerant level
damaged power board
Replace power board
“E8 or CE is
displayed
Dispense head
Dispense head not fitted correctly
Remove and refit Dispense Head
Dispense head Sensor loose
Check internal sensor
Dispense Head sensor broken
Change Dispense Head Sensor
“CL” is displayed
“CU” Error old
board
Mix low lock
Mix levels to low
Press STOP button, fill hoppers
and continue production
