2.
Lift the cover of the humidifier upwards and place
to the side (Fig. 70).
3.
Use a screwdriver to loosen and unscrew the four
screws at the surface of the control panel by
turning counter-clockwise (Fig. 71/1).
4.
NOTICE! The electronics of the control panel
are very sensitive. Ensure that you do not
touch the electronics and do not damage any
components.
Remove the control panel and place on the oper-
ating side (Fig. 72).
ð
The UV lamp is located in a metal housing
below the control panel (Fig. 73/1).
Fig. 70: Remove cover
Fig. 71: Loosening the control
panel
Fig. 72: Remove the control
panel
Accessories
2013-11-04Evaporation Humidifier B500 Professional76
