8.
Check the electrode rods for the water level meas-
uring (Fig. 26/1) for contamination. If required, use
a cloth or sponge to remove lime or other residues.
9.
Place center piece back into the water tank and
replace cover.
ð
The monthly cleaning is completed.
6.3.2
Replacing the evaporation filter
Spare evaporation filters can be ordered at your local
specialized retailer (order number: 1603).
Personnel:
n
Operator
L WARNING! Risk of electrical shock if the power
plug is not disconnected!
1.
Switch off humidifier and disconnect power plug.
2.
Lift the cover of the humidifier upwards and place
to the side (Fig. 27).
3.
Press filter bracket together and unhinge (Fig. 28).
Fig. 26: Clean electrode rods
Remove old filter
Fig. 27: Remove cover
Fig. 28: Remove filter bracket
Cleaning and servicing the humidifier
2013-11-04 Evaporation Humidifier B500 Professional 47
