09 COMPONENTS OF BKH PANORAMA
1
Image 1: BKH Panorama with lifting door
3
8
2
4
9
6
7
Image 2: BKH Panorama Section
EN | 57
EN
1 Cast iron dome with connecting piece 2 Body 3 Door with ceramic glass pane 4 Door handle 5 Combustion air adjusting lever 6 Combustion air opening or instal-
lation location for connection box (outside air connection, air intake flap actuator for electronic combustion control) 7 Catalytic converter 8 Bypass flap (opens/closes
when door is opened/closed, causing a noise) 9 Deflector plates
