1200 ON ON
2400 OFF ON
4800 ON OFF
* 9600 OFF OFF
Switch positions 3 and 4 are used as follows:
SW1-3 SW1-4
* Multidrop (8 data bits) and even parity check ON ON
Multidrop (8 data bits) and no parity check OFF ON
No Multidrop (7 data bits) and even parity check ON OFF
No Multidrop (7 data bits) and no parity check OFF OFF
To select one of the sixteen addresses for the machine it is necessary to set the last four
switches in accordance with the following table:
ADDRESSES S1-5 S1-6 S1-7 S1-8
* 0 ON ON ON ON
1 OFF ON ON ON
2 ON OFF ON ON
3 OFF OFF ON ON
4 ON ON OFF ON
5 OFF ON OFF ON
6 ON OFF OFF ON
7 OFF OFF OFF ON
8 ON ON ON OFF
9 OFF ON ON OFF
10 ON OFF ON OFF
11 OFF OFF ON OFF
12 ON ON OFF OFF
13 OFF ON OFF OFF
14 ON OFF OFF OFF
15 OFF OFF OFF OFF
* SW1 of the machine has been set as "OFF-OFF-ON-ON-ON-ON-ON-ON".
The switch settings of SW2 are:
ON OFF
SW2-1 pH Control pH Control
without dead band with dead band
SW2-2 Agitation Agitation
20-1000 RPM 20-1200 RPM
SW2-3 and SW2-4 can be set either "ON" or "OFF".
