LIST OF DRAWINGS
FIGURE 1 VESSEL ASSEMBLY
FIGURE 2 HEADPLATE ARRANGEMENT
FIGURE 3 THERMOWELL INSTALLATION
FIGURE 4 GAS DELIVERY SYSTEM
FIGURE 5 pH PROBE MOUNTING
FIGURE 6 D.O. PROBE MOUNTING (Phoenix Probe)
FIGURE 7 D.O. PROBE MOUNTING (Ingold Probe)
FIGURE 8 FOAM PROBE
FIGURE 9 EXHAUST CONDENSER
FIGURE 10 SAMPLING SYSTEM I
FIGURE 11 SAMPLING SYSTEM II
FIGURE 12 MEMBRANE KEYPAD
FIGURE 13 SEE SECTION 1.13
FIGURE 14 SEE SECTION 1.13
FIGURE 15 SEE SECTION 1.13
FIGURE 16 SEE SECTION 1.13
FIGURE 17 CABINET ASSEMBLY
FIGURE 18 SUGGESTED LOCATION OF IMPELLERS
FIGURE 19 SPARGER INSTALLATION
FIGURE 20 HARVEST TUBE INSTALLATION
FIGURE 21 POLYPROPYLENE PORTS
FIGURE 22 BEARING HOUSING IN STERILIZATION
FIGURE 23 BEARING HOUSING
FIGURE 24 FUSE REPLACING
FIGURE 25 CONTROL SCHEMATIC
