making these selections, move the cursor to the loop or the mode to be changed, then press
the "Alter" key to get the desired selection and then press "Enter" key. If you have a loop
set already, you cannot change into that loop.
SCREEN <MASTER> CALIBRATION GASES
Loop Name Agit 1 Temp 1 pH 1 DO2 1
Value 100 37.07.00100
Set 100 37.07.00100
Control PID PID PID PID
NOTE: The control mode of each loop are shown in the following table.
FEED 1 LVL 1
TO TO
LOOP AGIT 1TEMP 1 pH 1 DO2 1 AIR FEED 5 LVL 3
OFF OFF OFF OFF MON OFF OFF
PID PRIME PID PID MAN ADD
DO BASE
PID ACID HRVST
CONT LVL1
MODE LVL2
LVL3
ON
Figure 14
SCREEN <2-GAS> MASTER CALIBRATION
Oxygen Enrichment Air O2
Output % 75.5 24.5
Mode DO
Control Gains P 0.25 I 2.50
Figure 15
NOTE:
1. Mode can be off, Do, AgO2DO or manual. DO mode can be selected when
DO2 loop is in PID mode. AgO2DO mode can be selected when DO2 loop
is in PID mode and agitation is in DO mode.
2. P (Proportional) I (Integral) value can be selected by the operator. Move
cursor to O2, press code "9XXXX", then P I value can be changed.*
* NOTE: P I values have been set in the factory before shipping.
Under normal conditions, it is not necessary to reset
these values.
SCREEN <CALIBRATION> MASTER GASES
