ATTACHING RAIL CLOTH
(CONTINUED)
FIGURE SIX
Step #7: Staple three places along the rear edge of the
pocket facing X, then trim off excess cloth at pocket area.
Step #8: If rail is an end rail, repeat Step 7 at other corner
pocket. Then, starting at center of rails, stretch cloth
tightly over cushion and staple at bottom of rail working
toward each end.
FIGURE SIX
FIGURE SEVEN
Step #9: Trim excess cloth from bottom of rail ush with
edge of cloth relief groove.
FIGURE SEVEN
SIDE POCKET
FIGURE EIGHT
Step #10: At side pocket, stretch the cloth tightly over nose
of cushion and staple three places as shown.
FIGURE EIGHT
FIGURE NINE
Step #11: Slit the cloth up to the edge of cushion nose as
shown. Then rmly pull the small strip to the rear of the
cushion and staple at rear of facing.
FIGURE NINE
FIGURE TEN
Step #12: Hold the small fold in place with thumb and
forenger and rmly hold it down over facing. Then staple
at rear of facing and at bottom of rail as shown.
Step #13: Trim excess cloth as required.
FIGURE TEN
SmallFoldOn To p
OfSmallStrip
CANTON
BRUNSWICK INSTALLATION MANUAL PAGE 11
